OVERVIEW
-
Aperture detection and laser engagement system
-
For small drones, UAS group 1, in proximity of less than 1 km
-
Large field of detection (30°) and engagement (20°)
-
High speed beam steering of a focused laser (1.5 kW)
-
Capable of 20° deflection in less than 15ms
- Stationary mounted or fit onto existing carrier vehicles for mobile deployment
- Features an automatic, on site calibration routine
SPECIFICATIONS
Dimensions: (50 x 30 x 30) cm³
Weight: < 50 kg (Combiner without gimbal)
Optical interface: Fiber ports
Electrical: Industry standard interfaces
Field of view: 30° H x 30° V
Field of engagement: 20° H x 20° V
Step response (optical): < 15 ms for 20°
Stability (optical): <5 µrad
Product Variants
Zyklop™ - Laser drone shield
Art. No. 400650: Common aperture detection and laser engagement system for small drones. Large field of detection (30°) and engagement (20°) by high speed beam steering of a focused laser (1.5 kW), capable of 20° deflection in less than 15 ms.
